Applicable Industries: | fisheries |
Condition: | New |
Place of Origin: | Jiangsu, China |
Brand Name: | FOCUSUN |
Ice Shape: | ICE BLOCK |
Voltage: | 380V/220V (tailor made) |
Power: | 80 kw/tons |
Dimension(L*W*H): | 14016*4049*4000mm |
Weight: | 3500kgs |
Warranty: | 3 years |
Key Selling Points: | Automatic |
Ice storage capacity: | 25,000 kgs |
Machinery Test Report: | Provided |
Video outgoing-inspection: | Provided |
Warranty of core components: | 3 years |
Core Components: | Motor, Gear, Gearbox, PLC |
name: | automatic ice machine |
type: | good quality |
cooling way: | water cooling |
refrigeration gas: | R404a/R22 |
material: | stainless steel |
application: | fisheries |
compressor: | bitzer |
color: | sliver |
control system: | siemens |
ice shape: | block |
After Warranty Service: | Video technical support, Online support |
Local Service Location: | None |
Showroom Location: | None |
Certification: | CE |
After-sales Service Provided: | Field installation, commissioning and training, Video technical support, Online support |
Marketing Type: | Ordinary Product |
Packaging Details: | un-packaged, uses 40HQ container to transport |
Port: | shanghai |
Supply Ability: | 200 Set/Sets per Year |
Price: | $48,500.00/sets >=1 sets |
MOQ: | 1pc |
Company Info. |
Focusun Refrigeration Co., Ltd. |
Verified Supplier |
View Contact Details |
Product List |
FOCUSUN continues to provide brine system block ice machine with improved technology, largly improving the ice making efficiency. Put ice cans with full water in the brine tank, through heat exchange, the water in the ice cans all become ice. The crane will hoist a row of cans down into the ice thawing tank full of running warm water. So the ice surface thaws and gets separate from the ice can.
1.Patented UNI-EVEPTM processing technology ensures larger
evaporation area and higher cooling efficiency
2.The part inside brine tank that touches brine water is made of
SUS 304 which bears low temperature and highly resists rusts.
3.Particular can dumper and thawing tank design makes easier
operation.
4.Thawing tank is heated by air discharged from compressor to save
much energy and suits for low water temperature area.
5.Every brine block ice machine can be designed and built as per
your specific requirements.
MODE | DAILY PRODUCTION | REFRIGERANT | ELECTRICITY POWER | SIZE(L*W*H) |
FIB-100AHB | 1 TON | R404A | 4.8kw | 4000*1000*1200mm |
SPECIFICATIONS FOR 25 TON CRAWLER EXCAVATOR | ||||||
Engine | Engine model | Kw/rpm | 135.5/2150 | |||
No. of cylinders | Kw/rpm | 637/1800 | ||||
Net Power | L | 6.494 | ||||
Main performance parameters | Main performance parameters | km/h | 5.9/4.0 | |||
Travel speed (max. & min.) | ° | <=35 | ||||
Max. Gradeability | rpm | 11.3 | ||||
Hydraulic system | Hydraulic system | KPa | 50.1 | |||
Main pump | KN | 161 | ||||
Rate flow | KN | 125 |
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
If you are considering to purchase an ice machine, or you are just
want to know information about the ice machine and prepare your
business for future, please feel free to contact Focusun sales
team.
We are very interested to have your inquiry and looking forward to
give our best supports.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
![]() |
