New Energy Power Supply Battery Pack Special Water Dropper Thermistor 10K 100K 3950 High Precision NTC Thermistor
NTC temperature sensor is a kind of thermistor and probe. Its
principle is: the resistance value drops rapidly as the temperature
rises. It usually consists of 2 or 3 metal oxides, mixed in a
fluid-like clay, and calcined in a high-temperature furnace to form
a dense sintered ceramic. Actual size is very flexible, they can be
as small as 0.010 inches or very small diameter. There is almost no
limit to the maximum size, but usually under half an inch applies.
Type | NTC(thermistor) Temperature Sensor |
Temperature range | -50℃ ~ +300℃；Customized |
Accurancy | 1%；5%；10% |
RT(25℃) | 1K；2K；2.2k；2.7k；3K；5K；7K；8K；12K；15K；20K；25K；30K；40K；47K；50K；60K；70K；100K；200K；230K；250K；470K；500K；1000K；Customized |
B value | 3274；3435；3470；3928；3950；3977；4100；4200；4400；Customized |
Probe Material | Stainless steel SS304； aluminum；copper；plastic；epoxy；glass |
Installation | Flanged；Surface；Threaded；Plastic；Straight；Film；Customized |
Wire Material | Heat shrinkable tube；PVC tube；glass fiber tube； tube |
Connector | Molex；JST；DuPont；CWB；CJT；U type；Customized |
Waterproof | IP67；IP68 |
►Different NTC thermistor using in the NTC temperature sensors with the following different operating temperature:
Chip or MF52A,MF51E,MF55: temperature resist grade 125℃,actual
temperature resist grade 150℃
MF58: temperature resist grade 200℃,actual temperature resist grade
250℃
MF51: temperature resist grade 200℃,actual temperature resist grade
250℃
Special MF51: temperature resist grade 250℃,actual temperature
resist grade 300℃
Weldless chip:temperature resist grade 450℃,actual temperature
resist grade 500℃
►Operating environment
In the environment of high temperature,high humidty and high corrosion,we suggest to use glass sealed type thermistor as the core element.And MF51 type will be the best NTC thermistor in high humidity environment.
►Design considerations and procedure of temperature sensor:
1. Choose the shape acoording to customer's design or assemble
requirements, and confirm the thermistor.
2. Confirm the thermistor element and other materials according to
customers' requirement
3. Choose the suitable resistance,B value and tolerance
4. Choose suitable moisture-proof and insulation technology to meet
customer's requirement
5. Choose suitable encapsulation structure to meet performance
requirements of mechanical shock resistance
6. Meet customer's special requirements.
Working principle of temperature sensor
Using the NTC thermistor under a certain measurement power, the
resistance value drops rapidly as the temperature rises. Utilizing
this feature, the NTC thermistor can be used to determine the
corresponding temperature by measuring its resistance value, so as
to achieve the purpose of detecting and controlling the
temperature.
Reliability Test
| Test Item | Test Standard | Test method | Performance requirements |
| Zero Power Resistance | IEC 60539-1 | Immerse samples in the constant temperature bath at 25℃±0.005℃,test steady resistance | Resistance tol ±1% |
| B value | IEC60539-1 | Immerse samples in the constant temperature bath at 25℃,50℃(or 85℃), test steady resistance,and calculate B value | Resistance tol ±1% |
| Free fall | IEC60068-2-32 | Fall height: 1.5±0.1m,Surface: Cement , 1 time | No obvious damage, R25 △R/R≤±1% |
| Insulation | IEC60539-1 | 500V pressure on insulation shell test insulation resistance | >500MOhm |
| Withstand voltage | IEC60539-1 | Withstand voltage: 1500V/AC ,Leakage current:2mA Lasting: 60sec | No obvious damage |
| Tension | IEC60068-2-21 | Pull uniform speed at the end, F>4.0KG(requested by customer) | No obvious damage, R25 △R/R≤±1% |
| Vibration | Q/HBm 108-94 | Test frequency: 10~500Hz,swing: 1.2mm acceleration: 30m/s2 Direction X,Y,Z Time:8Hour/direction | No obvious damage, R25 △R/R≤±1% |
| Steady humidity and heat | IEC60068-2-78 | Temp:40±2℃ Humidity:92-95%RH Time:1000±24Hour | No obvious damage, R25 △R/R≤±1% |
| Thermal time constant | EC60539-1 | Immerse in 25℃ water,after thermal balance,immerse in 85℃,resistance arrives 63.2%,calculate total time | <10 sec |
| High temperature storage | IEC60068-2-2 | Temp:125℃±5℃ Time: 1000±24Hour | No obvious damage, R25 △R/R≤±1% |
| Cold and thermal shock | IEC60068-2-14 | -40℃~+125℃ T1:30min Cycle time:1000 | No obvious damage, R25 △R/R≤±1% |
| Knock experiment | IEC60068-2-77 | Acceleration:250m/s2 Pulse lasting: 6ms Knock times: 1000 Recovery time: 2 Hour | No obvious damage, R25 △R/R≤±1% |
| Low temperature storage | IEC60068-2-1 | Temp: 40±2℃ Time: 1000±24Hour | No obvious damage, R25 △R/R≤±1% |
| Salt spray | IEC60068-2-11 | Temp: 35±2℃ Collection hour : 1.0mL~2.0mL Time: determine per as actual demand | No obvious damage, R25 △R/R≤±1% |
