High Speed Industrial Laser Solutions 150m/min Automatic Feeding Metal Round Pipe

Categories Industrial Laser Solutions
Brand Name: DP LASER
Model Number: Laser Cutting Machine
Certification: CE SGS FDA TUV ROHS
Place of Origin: China
MOQ: 1 Set
Price: Please contact us
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 set/month
Delivery Time: 10-30 Work Days
Packaging Details: Wooden boxes that meet international export standards
Laser source: Raycus MAX IPG nLIGHT Laser Source
Laser power: 1000W-3000W
Power supply: 380V/50HZ
Maximum acceleration: 1.5G
Feature: SERVO-MOTOR
Cutting Speed: 150m/min
Cutting Thickness: 0-80mm
Weight (KG): 2000 KG
Cutting materials: Stainless Steel Carbon Steel Etc
After-sales Service Provided: Overseas engineers provide door-to-door service
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

High Speed Industrial Laser Solutions 150m/min Automatic Feeding Metal Round Pipe

High Speed Automatic Feeding Metal Round Pipe Fiber Laser Cutting Machine


The laser cutting machine is to focus the laser emitted from the laser into a high power density laser beam through the optical path system. The laser beam is irradiated on the surface of the workpiece, making the workpiece reach the melting point or boiling point, while the high-pressure gas coaxial with the beam blows the molten or vaporized metal away. With the movement of the relative position of the beam and the workpiece, the material is finally formed into a slit, so as to achieve the purpose of cutting.


Features

1. The speed is fast, the incision is smooth and flat, and generally no follow-up processing is required:


2. The cutting heat-affected zone is small, the plate deformation is small, and the cutting seam is narrow;


3. The incision has no mechanical stress and no shearing burr;


4. High machining accuracy, good repeatability, and no damage to the surface of the material;


5. Numerical control programming, can process any plan, can cut the whole board with large format, no need to open mold, economical and time-saving.


Applicable Industries

Mainly used in sheet metal processing, advertising sign production, high and low voltage electrical cabinet production, mechanical parts, kitchen utensils, automobiles, machinery, metal handicrafts, saw blades, electrical parts, glasses industry, spring sheets, circuit boards, electric kettles, medical micro Electronics, hardware, knives and measuring tools and other industries.

Apply toAuto feeding round pipeφ≤89mm,Square pipe≤63*63mm
Cutting accuracy±0.3mm,Tube bend≤2mm/m
Feeding length4000mm-6200mm

Primary filler weight


According to the size of the pipe, the storage space of the trough is limited, and the maximum load1.5t
Laser power1000W/1500W/2000W/3000W
Laser wavelength1070nm±5nm
laser modesingle mode
Photoelectric conversion efficiency30%
Working waycontinuous
Power adjustment range5-95%
Power instability≤2%
Transmission fiber core diameter25um-50um
Fiber length10m
Cooling methodWater cooling
Chiller modelC1000/C1500/C2000/C3000 Double temperature double circulation chiller
Cooling water temperature20-25℃
Power supplyAC380±10%,50/60Hz
Working temperature10~35℃
Working environment humidity≤95%
Total weight2T
