Categories | BGA Reballing Machine |
---|---|
Place of Origin: | Guangdong, China |
Brand Name: | WISDOMSHOW |
Certification: | CE |
Packaging Details: | icloud remove machine wds520 is packed by Wooden Box |
Price: | $980.00/Sets |
Condition: | New |
Machine Type: | Welding Positioner |
Applicable Industries: | Machinery Repair Shops, Manufacturing Plant, Retail, Construction works , Energy & Mining |
Showroom Location: | None |
Video outgoing-inspection: | Provided |
Machinery Test Report: | Provided |
Marketing Type: | Hot Product 2019 |
Warranty of core components: | 1 Year |
Core Components: | Infrared preheating board |
Warranty: | 1 Year |
Key Selling Points: | Infrared preheating |
Weight (KG): | 35 |
Voltage: | 220/110V |
Current: | 50/60hz |
Rated Capacity: | N |
Rated Duty Cycle: | N |
Dimensions: | L460mm*W480mm*H500mm |
Usage: | mobile phone/laptop BGA/IC rework and repair |
Electrical Material: | Touch screen+Temperature control module+microcontrollers |
Total Power: | 3800W |
PCB size: | Max 300mm*280mm Min 10mm*10mm |
BGA Chip Size: | Max 60mm*60mm Min 1mm*1mm |
Power: | Ac220v ±10%,50hz |
Heater power: | Upper temp.one 800w,second temp.zone1200w,IR temp.zone 1800w |
PCB thickness: | 0.3-5mm |
Weight: | 20KG |
position way: | V-shape card slot +universal jigs |
operation type: | manual |
After Warranty Service: | Video technical support, Online support |
Local Service Location: | None |
After-sales Service Provided: | Video technical support, Online support |
Power supply | AC 220V±10% 50Hz |
Total power | 3800W |
Heater power | Upper temp.zone 800W,second temp.zone 1200W,IR temp.zone
1800W(1200W controlled) |
Electrical material | Touch screen+Temperature control module+microcontrollers |
Locating way | V-shape card slot+Universal jigs |
PCB size | Max 300mm*280mm Min 10mm*10mm |
Applicable chips | Max 60mm*60mm Min 1mm*1mm |
PCB thickness | 0.3-5mm |
Overall dimension | L460mm*W480mm*H500mm |
Weight of machine | 20KG |
Usage | Repair chips / phone motherboard etc. |
![]() |
