| Categories | Open Frame Touch Monitor |
|---|---|
| Brand Name: | GreenTouch |
| Model Number: | GT-TM-1502C |
| Certification: | CE, FCC, ROHS |
| Place of Origin: | China |
| MOQ: | 1 |
| Payment Terms: | MoneyGram, Western Union, T/T, D/P |
| Supply Ability: | 3,000pcs per month |
| Delivery Time: | 10 working days after received your payment |
| Packaging Details: | Packed in carton firstly,and then reinforced with wooden case for outer packing |
| Screen Ratio: | 4:3 |
| Response time: | 8ms |
| Pixel Pitch: | 0.297x0.297mm |
| Display type: | TFT LCD panel |
| Resolution: | 1024X768 |
| Contrast Ratio: | 450:1 |
| Support color: | 16.7M |
Open Frame TFT LCD15 Inch Touch Screen Monitor VGA / USB Metal Case
10.4 Inch lcd Monitor
Description:
| Model Number | GT-TM-1502C |
| Display type | TFT LCD panel |
| Screen Ratio | 4:3 |
| Resolution | 1024X768 |
| Active area | 305X228(mm) |
| Brightness | 250cd/m2 |
| Contrast Ratio | 450:1 |
| Support color | 16.7M |
| Response time | 8ms |
| Pixel Pitch | 0.297x0.297mm |
| Viewing Angle | Horizontal(L/R):85°/85° Vertical(Up/Down):80°/80° |
| Video input | DVI,VGA |
| Scan Frequency | Horizontal:30~80KHz ,Vertical: 56.3~75Hz |
| Power Input | Support AC 100 ~ 240V,50 ~ 60Hz,DC12V-3A |
| Environment | Operating temperature:0 to 50°C Storage temperature:-20 to 60°C |
| Operating humidity:20% to 80% Storage humidity:10% to 90% | |
| Mean Time Between Failure (MTBF) | 30,000 hours |
| Backlight working life(Typ.) | 50,000 hours |
| Touch screen Type | Capacitive touch screen |
| Touch life | Over 5,00 million times |
| Touch object | Finger or touch pen |
| Touch screen interface | USB or RS232 interface |
| Power consumption | Max 21W |
| Certificates | CE, FCC |
| Button | POWER,MENU,AUTO,UP,DOWN |
| Warranty | 1 year |
Special for desktop public service inquiry system,POS systems,
hotel reception, self-service, ATM,industrial manufacturing,
Hospital information center, information systems and other
interactive touch application design .
Packing and shipping:
Competitive Advantage:
GreenTouch's Open Frame Monitor is designed for commercial and industrial applications where the this open frame screen goes into a larger unit that already has a bezel or other framing.products have passed CE, FCC certification.It can accept a multitude of common video inputs including multiple VGA and DVI. High Performance and Reliability.
Product overview
GreenTouch's Industrial monitor is designed for commercial and
industrial applications where the this open frame screen goes into
a larger unit that already has a bezel or other framing.It can
accept a multitude of common video inputs including multiple D-Sub
, VGA and DVI.
GreenTouch has a wide assortment of high quality LED and LCD Open
Frame Monitor for Automation, kiosks, arcade games, digital
entertainment display, ATM machines, and any umber of commercial
and military applications. designed withall-plasticergonomic shell,
and new energy-saving drive board .
|
