| Categories | SFP Module Transceiver |
|---|---|
| Brand Name: | Olycom |
| Model Number: | OSPL1G20D |
| Certification: | CE RoHS FCC |
| Place of Origin: | Shenzhen, China |
| MOQ: | 1Pcs |
| Price: | Negotiable |
| Payment Terms: | T/T, Paypal |
| Supply Ability: | 5000Pcs per week |
| Delivery Time: | 3~7 working days |
| Packaging Details: | 1 piece in 1 carton. 0.2KG/pcs |
| Product name: | 1000Base-LX 1.25G SFP Transceiver |
| Distance: | 20KM LR |
| Wavelength: | 1310nm, single mode |
| Fiber port: | LC, duplex |
| Transmission rate: | 1.25Gb/s |
| Working Temp: | -40°C to 85°C |
| Company Info. |
| Shenzhen Olycom Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
1000Base-LX 1.25G SFP Transceiver With 1310nm Dual LC Connector 20KM Single Mode DDM For Cisco Meraki Ubiquiti Mikrotik
Product Overview
OLYCOM OSPL1G20D Transceiver is a high performance, cost effective module which have a duplex LC optics interface. Standard AC coupled CML for high speed signal and LVTTL control and monitor signals. The receiver section uses a PIN receiver and the transmitter uses a 1310 nm FP laser, up to 15dB link budge ensure this module 1000Base Ethernet 20km application.
Features
Applications
Parameters
| Parameter | Symbol | Min. | Typical | Max. | Unit | Note |
| Transmitter Section: | ||||||
| Center Wavelength | λc | 1270 | 1310 | 1360 | nm | |
| Spectral Width(RMS) | σRMS | 3 | nm | |||
| Optical Output Power | Pout | -9 | -3 | dBm | 1 | |
| Extinction Ratio | ER | 8.2 | dB | |||
| Optical Rise/Fall Time | tr / tf | 260 | ps | 2 | ||
| Relative Intensity Noise | RIN | -120 | dB/Hz | |||
| Output Eye Mask | Compliant with IEEE802.3 z (class 1 laser safety) | |||||
| Receiver Section: | ||||||
| Optical Input Wavelength | λc | 1260 | 1360 | nm | ||
| Receiver Overload | Pol | -3 | dBm | 4 | ||
| RX Sensitivity | Sen | -24 | dBm | 4 | ||
| RX_LOS Assert | LOS A | -35 | dBm | |||
| RX_LOS De-assert | LOS D | -25 | dBm | |||
| RX_LOS Hysteresis | LOS H | 0.5 | dB | |||
| General Specifications: | ||||||
| Data Rate | BR | 1.25 | Gb/s | |||
| Bit Error Rate | BER | 10-12 | ||||
| Max. Supported Link Length on 9/125μm SMF@1.25Gb/s | LMAX | 20 | km | |||
| Total System Budget | LB | 15 | dB | |||
|
